FRAME
FRAME
Aluminium Superlite, Gravity Casting Technology, Efficient Comfort Geometry, Fully Integrated Battery, 1.5 Headtube
SIZE
Men: S (50cm), M (54cm), L (58cm), XL (62cm); Trapeze: XS (46cm), S (50cm), M (54cm); Easy Entry: XS (46cm), S (50cm), M (54cm), L (58cm)
SUSPENSION
SUSPENSION FORK
SR Suntour NVX30 Coil, 63mm
E-BIKE SYSTEM
DRIVE UNIT
Bosch Drive Unit Performance Generation 3 (75Nm) Cruise (250Watt), Smart System
BATTERY
Bosch PowerTube 625
REMOTE
Bosch LED Remote
CHARGER
Bosch 4A
DRIVETRAIN & BRAKES
BRAKE SYSTEM
Shimano BR-MT200, Hydr. Disc Brake (180/180)
REAR DERAILLEUR
Shimano RD-M3100-SGS, 9-Speed
SHIFTERS
Shimano SL-M3100-R, Rapidfire-Plus
CRANKSET
ACID E-Crank, 38T, 175mm (EE: 170mm)
CASSETTE
Shimano CS-HG201, 11-36T
CHAIN
KMC X9
COCKPIT
HANDLEBAR
CUBE Comfort Trail Bar, 720mm
STEM
CUBE Performance Stem Pro, 31.8mm
GRIPS
ACID Hybrid Tour
HEADSET
ACROS AZF-1031, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
WHEELS
FRONT HUB
Shimano HB-TX505, QR, Centerlock
REAR HUB
Shimano FH-TX505, QR, Centerlock
RIMS
Rodi Blackrock 23, 32H, Disc, Tubeless Ready
TYRES
Schwalbe Land Cruiser, Active, K-Guard, 55-622
FINISHING KIT
SEAT POST
CUBE Performance Post, 30.9mm
SADDLE
Natural Fit Sequence Comfort
PEDALS
ACID PP Trekking
FRONT LIGHT
CUBE Shiny 50 Lux, 12V, DC
REAR LIGHT
ACID Mudguard Rear Light PRO-E, 12V, DC
KICKSTAND
ACID FM Pure Kickstand
MUDGUARDS
ACID 65 BB-Mount
BELL
Easy Bell
