Frame
C:62 Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
Size
M (18"), L (20"), XL (22")
Fork
RockShox ZEB Select Charger RC, 15x110mm, Tapered, eMTB Approved, 170mm
Shock
RockShox Deluxe Select+, 205x65mm, Rebound Adjust, Trunnion Mount, Lockout
Shock Hardware
Top: 54mm Trunnion Mount, Bottom: 22.2x8mm
Drive Unit
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
Battery
Bosch PowerTube 750
Display
Bosch Kiox 300
Charger
Bosch 4A
Brake System
Shimano Deore BR-M6120, Hydr. Disc Brake (203/203)
Rear Derailleur
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Shifters
Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus
Crankset
ACID E-Crank, 165mm, 36T
Chain Guide
Reverse Flip-Guide E-Kettenführung, Direct Mount, GEN4
Cassette
Shimano Deore CS-M6100, 10-51T
Chain
Shimano CN-M6100
Wheelset
Newmen Performance 30, 28/28 Spokes, 15x110mm/12x148mm, Tubeless Ready
Front Tire
Maxxis Assegai, MaxxGrip/EXO+, Tubeless Ready, 2.5 WT
Rear Tire
Maxxis Minion DHR II, MaxxGrip/DoubleDown, Tubeless Ready, 2.4 WT
Stem
CUBE Performance Stem E-MTB, 31.8mm
Handlebar
Newmen Evolution SL 318.25, 780mm
Grips
ACID Disrupt, Soft Compound
Seat Post
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm (M: 125mm, L,XL: 150mm)
Seatclamp
CUBE Screwlock Semi Integrated, 34.9mm
Saddle
Natural Fit Venec
Headset
ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
Weight
24,5 kg
Colour
polarsilver´n´orange
